TGB BLADE 1000 LTX EPS
$12,134.00
PERFORMANCE AND BREAKTHROUGH
Blade 1000 LT EPS is equipped with an 83 HP strong V-twin engine, 4WD/2WD switchable with front/rear differential lock, unmatched higher ground clearance and 52° increased front approach angle. Blade 1000 LT EPS would definitely renew your impressions to 1000 cc ATV. Mirrors not included. Can be purchased separatelyWARRANTY
2 Year Limited Warranty
Find A Dealer
Service Manual
Technical Specification
| TGB BLADE 1000 LTX EPS | |
| Engine Type | 997 cc, V-twin, SOHC |
| Ignition | ECU |
| Starter | Electric |
| Bore X Stroke | Ø 92 × 75 mm |
| Compression Ratio | 10.2 |
| Fuel System | 50 mm Throttle Body / Programmed Fuel Injection |
| Max Power | 83 HP / 7000 rpm |
| Max Torque | 89.9 Nm / 5500 rpm |
| Drive System | 4 × 4 Shaft Drive |
| Gear Selection | L / H / N / R / P |
| Transmission | V-Belt CVT Automatic |
| Engine Braking System | Standard |
| Over Ride Button | Standard |
| Front Suspension | Dual A-arm |
| Rear Suspension | Dual A-arm with Anti-roll Bar |
| Front/Rear Brake | Hydraulic Disc with piston caliper and Hydraulic Foot Brake |
| Parking Brake | Park In Transmission / Lockable Hand Lever |
| Front Tire | AT 26 × 9 – 14 , 6 PLY |
| Rear Tire | AT 26 × 11 – 14 , 6 PLY |
| Wheelbase (mm) | 1460 |
| Length/Width/Height (mm) | 2340 X 1255 X 1340 |
| Fuel Capacity | 23 L |
| Electrical Outlet Connector | 2 DC 12V 10A 120W |
| Instrumentation | Digital instrument panel with odometer, speedmeter, Tripmeter, RPM, transmission position, fuel gauge, Hi-Temp/Low-Battery lights, high beam light, EFI checking, differential indicator, 2WD/4WD indicator, EPS indicator |
| Color | Matte Black with Red decal, Matte Black with Yellow decal, Mountain Grey with Red decal, Camo |
| Estimated Dry Weight (kg) | 578 kg |
